Place of Origin: | CHINA |
---|---|
Brand Name: | JULI |
Certification: | ROHS,REACH,FDA |
Model Number: | Y5 |
Minimum Order Quantity: | 1CubmicMeter |
Price: | USD190-220/CUBMIC METER |
Packaging Details: | Woven Bag,10-15kg/Bag |
Delivery Time: | 5-8 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 1000 CUBMIC METERS/MONTH |
Material: | HDPE | Color: | White |
---|---|---|---|
Size: | 25*12mm | Application: | Waste Water Treatment |
Product Name: | MBBR Biofilm Technology Kaldnes Bio Filter K1 Media | Sample: | Free Sample Is Avaliable |
Highlight: | Y5 HDPE MBBR Biofilter Media,JULI mbbr carrier media,JULI MBBR Biofilter Media |
Large Surface Area Biofilm Carrier With Super Decarburization And Virgin HDPE Material
MBBR Media -HDPE Biocell Filter Media for Wastewater
Moving Bed Biofilm Reactor (MBBR) processes improve reliability, simplify operation, and require less space than traditional wastewater treatment systems.
The MBBR process can be used for a variety of different applications to attain the desired results, depending on the quality of the wastewater and the discharge regulations.
Application:
1) All types of industrial and domestic wastewater.
2) Both organic as nitrogen removal.
3) New plants or system upgrades.
4) Limited footprint.
Main Features:
(1) Scientific formula, rapid forming biofilm
(2) Large specific surface area, attachment more microorganism
(3) Easy fluidization, low energy consumption
(4) Flexible dosing ratio, high load capacity
MBBR Filter Media Working Principle:
1. Special design of surface, stronger bio-film growth capacity;
2. Large specific surface area, high voidage, the more periphyton biomass;
3. Unique design of structure and shape according to hydromechanics, strong three-dimensional flow dynamics in the water;
4. Adding hydrophilic groups and other trace elements, the biofilm formation time only 3-15 days;
5. Excellent impact strength, strong gas shear capacity;
Product Parameter:
ITEM | Y1 | Y2 | Y3 | Y4 | Y5 | |
Rooms | rooms | 4 | 5 | 19 | 6 | 64 |
Size | mm | 11*7 | 10*7 | 25*10 | 16*10 | 25*4 |
Effective specific surface area | m2/m3 | 900 | 1000 | 600 | 800 | 1200 |
Density | g/cm3 | 0.95±0.02 | 0.95±0.02 | 0.95±0.02 | 0.95±0.02 | 0.95±0.02 |
Stacked | Pcs/m3 | >830000 | >850000 | >97000 | >260000 | >210000 |
Porosity | % | >85 | >85 | >90 | >85 | >85 |
Dosage | % | 15-68 | 15-70 | 15-67 | 15-67 | 15-70 |
Nitrification efficiency | gNH4-N/m3*d | 400-1200 | 400-1200 | 400-1200 | 400-1200 | 400-1200 |
BOD5 oxidation efficiency | gBOD5/m3*d | 2000-10000 | 2000-10000 | 2000-10000 | 2000-10000 | 2000-10000 |
COD oxidation efficiency | gCOD/m3*d | 2000-15000 | 2000-15000 | 2000-15000 | 2000-15000 | 2000-15000 |
proper temperature | ℃ | 5-60 | 5-60 | 5-60 | 5-60 | 5-60 |
Service life | Year | >20 | >20 | >20 | >20 | >20 |
Bulk Density | Kg/m3 | 135kg | 145kg | 95kg | 120kg | 135kg |
